This is a 4 Inch Round 1-LED Trailer Light that integrates braking, steering, and taillight functions. The product complies with SAE standards, adopts ultrasonic sealing technology, achieves IP65 protection level, and uses PL-3 three wire interface connection.
Our 4 Inch Round 1-LED Trailer Light core advantages:
Economical and practical, single LED design, high cost-effectiveness
Reliable sealing, ultrasonic sealing process ensures IP65 protection level
Standard interface, using the universal PL-3 three wire interface, with good compatibility
The lens is made of PMMA material, with high light transmittance and good weather resistance. The outer shell is made of ABS engineering plastic, which is sturdy, durable, and impact resistant
|
Size |
4-inch Round |
|
Mounting |
Grommet Mount |
|
IP Rating |
IP65 |
|
LED Quantity |
1 LED |
|
Connector |
3-Wire PL-3 Connector |
|
Material |
PMMA Lens / ABS Housing |
|
Function |
Stop / Turn / Tail Light |
|
Certification |
SAE Certified |
Our 4 Inch Round 1-LED Trailer Light can be used for small trailers and trailers, utility trailers， Agricultural equipment, marine trailers
Certificate/Standard: Compliant with SAE certification standards
IP65 protection level, suitable for various weather conditions
Ultrasonic sealing process ensures long-term waterproof performance
Standard PL-3 interface, easy to install
Connect the vehicle circuit through the PL-3 three wire interface
Use rubber sheath for embedded installation
Confirm the correct circuit connection before installation
Ensure that the sealing ring is intact and undamaged
Do not cover or damage the surface of the lens
